Material : As per IS 1865 Gr. 400/15 (Ductile Iron)
Brinell Hardness: 130 to 180 BHN
Tensile Strength: 400N/mm² (minimum)
Elongation: 15% (minimum)

Threading : Conforming to BSP, parallel female and taper male threads as per IS 554/BS 21/ISO 7

Finish : Hot Dip Galvanized finish having Zinc coating of more than 610 gms/m² is done in accordance with the provisions contained in IS 4759 & IS 2633.

Special Notes
1. Pipe fittings are recommended for those gases and fluids only, which do not react with the material of construction.
2. All dimensions given in the product pages are in millimeters.
3. Fittings are also randomly tested on a pneumatic pressure of 10 kg/cm²g.
4. Ungalvanized (Black) fittings can also be supplied on request.
5. Owing to our ever continuous product development, dimensions and materials are subject to change without any prior notice.
